EH0101:Atari 8 Bit AV Break Out Box $28.00
 |
More Details: This breakout box(b.o.b.) uses standard phono cables for video, chroma, luminance, and audio, and will accept an s-video plug/cable. These video outputs will provide a superior picture over using the RF jack on the 8 bit console. For the phono cables, hold the b.o.b. and push in the cables with a slight twist. Remove with a slight twist as well. Use care to hold the s-video cable the right way, usually with the flat side up(towards the label). For longer distances, higher quality cables are recommended. The 8 bit monitor plug inserts into the jack (on the right side or center back) with the 5 pins at the bottom. Note that some 8 bit models do not have monitor jacks. And some with the jacks do not have the chroma line connected. Testing has shown that a short jumper between the video and chroma jacks will provide a signal suitable for s-video, although of lower quality than using an actual chroma signal. Also, this b.o.b. will NOT provide RGB or VGA signals. These signals are not present on the 8 bit monitor jack. |
ORDERING(all funds US$):
8 bit Atari AV Break Out Box(BOB) #EH0101($28.00)
 |
PAYPAL |
Mail Order |
|
Ship in US except Texas: Price(1): Price+ship/hand+PP Fee |
Total $36.77 |
Total $35.39 |
|
Ship in Texas: Price(1): above+Sales Tax |
Total $39.41 |
Total $37.95 |
|
Ship in Canada: Price(1): above |
Total $44.00 |
Total $41.90 |
|
Ship Elsewhere- 1st Int'l: Price(1): above |
Total $47.74 |
Total $45.50 |
|
Ship Elsewhere- 1st PMI: Price(1): above |
Total $82.16 |
Total $78.60 |
(1stI=First Class International(NO INSURANCE!), PMI=Priority Mail International(Faster & Indemnity USUALLY Included!))
(Mail Order Note:Money Orders and Cashiers Checks process faster than personal/business checks.)
Please ask FIRST:
Shipping elsewhere, Adding Insurance, Multiple items, Questions.
Get info BEFORE ordering.
By MAIL
Check, Money Order, Cashiers Check(DO NOT SEND CASH)
More Than Games
8207 Briarwood Lane
Austin TX 78757
